3-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: N/A
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 1-30 working days
Payment Terms: T/T, L/C
Supply Ability: 30,000pcs/month
Product Name: High Density Fabrication Customized 3-10L HDI PCB Manufacturing Service Feature: 3-10L HDI
Base Material: FR-4, TACONIC, Aluminum, CEM-3, Metal/ceramic/aluminum Base Min. Line Spacing: 1.6mm, 0.2-6.0mm, 0.2mm-6.00 Mm(8mil-126mil), 0.5~3.2mm, 1.6 Mm
Solder Mask: Green, White Black Green Blue Red, Green Or Other Color As You Want, Green/blue, Green Black Bule White Application: Electronics Device, Consumer Electronics, Communications, And So On, Universal
Solder Mask Color: Green, Blue, White And Red, White Black Yellow Green Red, Purple Testing Service: 100% Electrical Test, Fly-probe, Function Testing, 100% E-testing, Flying Probe Testing
High Light:

10L HDI PCB 100% Electrical Test


10L high density pcb


TACONIC Aluminum high density pcb

High Density Fabrication Customized 3-10L HDI PCB Manufacturing Service



What can we do?

1. Provide HDI PCB board service
2. Provide 2-68 layers samples to mass production service
3. Common PCB/HDI PCB/FPC/rigid-flex PCB/metal substrate
4. ISO9001, ISO14001, UL, IATF16949 certification



Industrial application


High-power industrial applications of HDI PCBs are common. These electronic components control the mechanisms used in factories and manufacturing facilities and must withstand the harsh conditions commonly found in industrial installations. This can include anything including harsh chemicals, vibrating machinery and rough handling.
In such a rapidly challenging environment, industry standards are equally stringent. Currently, thick copper PCBs (much thicker than standard ounce PCBs) are often seen in other applications. This PCB is helpful for high current industrial applications and battery chargers.
1. Industrial Equipment: Many drills and presses used in manufacturing operate using PCB-controlled electronics.
2. Measuring Equipment: Equipment used to measure and control pressure, temperature and other variables in industrial manufacturing processes.
3. Power equipment: DC-AC power inverter, solar cogeneration equipment and other power control equipment.



PCB Capacities and Technical Specification


NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm



Company introduction


CESGATE has been a professional supplier of PCB fabrication, PCB assembly and components sourcing turnkey solutions since 2010. With a strong sales and technical support team, CESGATE is online 24 hours per day to meet customers' needs. Dedicated to improving prototypes for design engineers through the production process, from quotation to delivery, from PCB design and layout, PCB fabrication and turnkey PCB assembly, CESGATE offers unparalleled customer service.


Advanced PCB Manufacturing and PCB Assembly Equipment


CESGATE has imported the advanced machinery from US,Japan,German and Israel to improve our production and technical ability.We have set a great example the PCB field of flying probe testing,buried and blind via and special controlled impedance.We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.


3-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 03-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 13-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 23-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 33-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 43-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 53-10L HDI PCB TACONIC Aluminum High Density PCB 100% Electrical Test 6



Q: What is needed for PCB & PCBA quotation?
CESGATE: For PCB: Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness) and quantity you need.
For PCBA: Files mentioned above, BOM, pick and place file.
Q: Are my files safe?
CESGATE: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.
If requested by the client, we will sign an NDA subject to local laws on the client's side and promise to keep client data highly confidential.
Q: What are the main products of your PCB/PCBA services?
CESGATE: Automotive, Military, Aerospace, Industry Control, Medical care, IOT, Smart Home, Robot, Auto parts, Camera, UAV.
Q: What is your minimum order quantity (MOQ)?
CESGATE: Our MOQ is 1 PCS, we are able to handle Small as well as large volume production with flexibility.
Q: Are you factory?
CESGATE: Our factory is located in Building 6, Fuyuan industrial park, Qiaotang road, Fuyong street , Shenzhen city, China
