Taconic TP High Frequency PCB Flex Rigid 600mm*1200mm Multilayers Customization

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: ISO9001/ ISO14001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 1-30 working days
Payment Terms: T/T, L/C
Supply Ability: 30,000pcs/month
Product Name: Taconic TP High Frequency PCB Flex Rigid 600mm*1200mm Multilayers Customization Feature: PCB/Customization
Min. Line Width: 0.2mm, 3mi, 0.075mm, 0.075mm/0.075mm(3mil/3mil), 0.1 0mm Outer Cu Weight: 0.5-4 0z
Sub-assembly: Plastic,metal,screen Min Trace/gap: 0.075mm Or 3mil
Copper Thickness: 1oz, 1/2OZ 1OZ 2OZ 3OZ, As Your Request, 0.5-3.0 Oz, 1 Oz Base Material: FR4, Aluminum, Rogers, TG
High Light:

Taconic TP High Frequency PCB

,

600x1200 MM High Frequency PCB

Taconic TP High Frequency PCB Flex Rigid 600mm*1200mm Multilayers Customization





What is PCB?



Printed circuit board, also known as printed circuit board, printed circuit board, often used in English abbreviations are high frequency PCB (Printed circuit board) or PWB (Printed wire board). PCB is the base plate used to assemble electronic components, and it is also the "mother of electronic products". It is a very important electronic component and a support for electronic components. Mainly through the metal copper foil circuits on the board, through the design of each layer to connect and conduct related components, to achieve a complete product that operates effectively.

Before the early PCB appeared, the various components of electronic products were connected by wires to form a complete path. Later, in order to simplify the manufacturing process of electronic products and reduce the cost, the circuit was developed by printing, and the copper foil on the substrate was used to replace the original wire connection, thereby improving the production efficiency.

The various components are mainly connected through the metal copper foil circuits on the board. By designing each layer to connect and conduct related components, a complete product that operates effectively is achieved.

The traditional circuit board construction method uses printed resists to make circuit lines and drawings, so it is called printed circuit board. Because the size of electronic products continues to be miniaturized and refined, most circuit boards are currently covered with etching resists (wet film or dry film), which are exposed and developed and then etched to remove unwanted copper foil to make circuit boards.





Military Applications of PCBs


You can use High Frequency PCBs in a wide range of applications in the military. For instance.in the firearms and ammunition.
Manufactures of firearms such as guns, explosives, and ammunition use High Frequency PCBs to ensure they are safe and functional.
They will use equipment such as penetration shock recorders or impact testing devices before releasing them for usage.





PCB Capacities and Technical Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm
