High TG Semiconductor PCB Printed Circuit Board Prototype Nelco Laminate

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: N/A
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 1-30 working days
Payment Terms: T/T, L/C
Supply Ability: 30,000pcs/month
Product Name: Multilayer ENIG High TG Prototype Semiconductor PCB Industry Production Feature: High TG
Base Material: FR-4, TACONIC, Aluminum, CEM-3, Metal/ceramic/aluminum Base Type: Semiconductor Tools Systems And Components, Equipment Comp
Solder Mask: Green, White Black Green Blue Red, Green Or Other Color As You Want, Green/blue, Green Black Bule White Application: Electronics Device, Consumer Electronics, Communications, And So On, Universal
Solder Mask Color: Green, Blue, White And Red, White Black Yellow Green Red, Purple Min Space/line: 0.075mm
High Light:

High TG printed circuit board prototype

,

printed circuit board prototype Nelco laminate

,

High TG Semiconductor PCB

Multilayer ENIG High TG Prototype Semiconductor PCB Industry Production





Semiconductor PCBA Manufacturing Service Requirements



Build Flexibility


Semiconductor boards must often transmit, receive, and process various signal types, interconnect using different types of connectors, and perform in unique environments. Therefore, your CM must excel in all types of board building, and they must meet IPC Class 1, 2, and 3 performance level standards. Additionally, they should be able to manufacture non-standard form factors.


Secure Component Procurement


For turnkey, your CM is responsible for procuring components (with the possible exception of exotic components) from a secure supply chain that is free of counterfeits and obsolete components.
Quality Assembly


Semiconductor PCBA reliability is only attainable with quality assembly. Your board’s ability to last throughout its intended lifecycle depends on high-quality solder connections for both SMDs and through-hole components.


Process Agility


Design changes may be required to add or improve functionality or meet customer demands. Time may be of the essence here, and your CM needs an agile manufacturing process that can incorporate changes quickly with minimal process adjustments or the need for additional equipment.


Accurate and Accessible Documentation


As semiconductor PCBAs may experience multiple revisions or integration into other design projects, accurate and thorough documentation is mandatory.



While other considerations may arise when assessing a CM’s ability to meet your turnkey semiconductor service needs, ensuring it can satisfy the requirements listed above is essential.



Semiconductor PCB and Printed Circuit Board (PCB) Manufacturing



CESGATE has become a titan of the semiconductor production market, defining industry standards while increasing market share and combining its long-standing experience with that of major semiconductor component manufacturers. We are a supplier of reliable, high-performance consumables and equipment for all process steps, starting with wafer manufacturing and lithography processes, right up to packaging, assembly, and inspection. Our focus is the production of zero-failure solutions with optimised cost efficiency in the fields of lithography, RTP (rapid thermal processing), cleaning, inspection, and measurement.

Depending on which process you wish to achieve, CESGATE will be happy to call on its unmatched experience across the entire light spectrum to recommend the right ultraviolet (UV), vacuum-ultraviolet (VUV), or infrared (IR) emitter. Click the icons below to explore the semiconductor PCB and printed circuit board (PCB) processes which CESGATE is able to assist you with.





PCB Capacities and Technical Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm
