Metal Core Fr4 Printed Circuit Board Four Layer PCB Green ENIG

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: ISO9001/ ISO14001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 1-30 working days
Payment Terms: T/T, L/C
Supply Ability: 30,000pcs/month
Product Name: Customized FR4 Metal Core Printed Circuit Board Multilayer PCB Green ENIG Layers: 1-68
Board Thickness: Single/Double:0.008±0.004” Outer Cu Weight: 0.5-4 0z
Sub-assembly: Plastic,metal,screen Min Trace/gap: 0.075mm Or 3mil
Keyword: MULTILAYER PCBS Bow&twist: ≤0.5%
High Light:

Metal Core fr4 printed circuit board

,

fr4 printed circuit board Green ENIG

,

four layer pcb Green ENIG

Customized FR4 Metal Core Printed Circuit Board Multilayer PCB Green ENIG





Briefly Introduce Our Multilayer PCBs



CESGATE stores enough raw materials in our warehouse for a long time to shorten the lead time and reduce the waiting time of customers, Common materials are: KB, Shengyi, Iteq, Nanya, Rogers, Isola, Arlon, Taconic, Ventec, Dupont, Tellon, Panasoic, Berquist., etc. CESGATE specializes in multilayer PCB manufacturing. Our factory is located in the core of the Pearl River Delta PCB industry cluster, and our products are widely used in industrial control, communications, new energy, automobiles, medical equipment, security, aerospace and other fields.



Electronics make a major contribution to health - the nursing industry, as diagnostic, monitoring and therapeutic equipment. As the development of electronics becomes more efficient and dense, the medical applications of these electronic devices continue to grow, leading to endless new possibilities.


At the heart of these medical devices is the multilayer PCB. PCBs in the medical industry are highly specialized to accommodate the unique constraints of medical devices. In many medical applications, small packages are required to meet the size requirements for implants or emergency room monitors. Therefore, medical multilayer PCBs tend to be specialty high-density interconnect PCBs, also known as HDI PCBs. Medical PCBs can also be made with flexible substrates that allow the PCB to bend during use, which is essential for both internal and external medical devices.


Medical PCBs are held to a higher standard than most other PCB types due to the health concerns associated with them. In addition to complying with strict medical regulations, repeatability and reliability are two essential qualities that medical PCB suppliers must achieve.


Medical PCB applications are growing as fast as the medical device industry itself. Some of the most common medical PCB applications include:


1. Monitors: Personal and healthcare monitors, including blood glucose monitors, heart rate and blood pressure monitors, and more.
2. Scanning Technology: CT scanners and ultrasound technology typically use PCB-based electronics.
3. Control System: The device controls the infusion, flow rate and distribution are electronically controlled.
4. Internal Devices: Pacemakers and similar internal medical devices keep patients healthy and are operated by a central micro-PCB.
5. Scientific Instruments: Medical research uses a large number of scientific instruments to study diseases and test the results of patients. These include electron microscopes, photometers, and generator and compressor control systems, among others.



PCB Capabilities



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm





Company introduction



CESGATE is an OEM manufacturer that focus on PCB manufacturing & PCB Assembly over 20 years. We have the capability to manufacture pcb ranging from basic single sided boards up to 48 layer multilayers, and provide one stop turnkey services, including PCB manufacture, PCB assembly, components source, function testing services and housing so on.We always provide high quality, technically advanced products within the customer’s timescales so that we can provide the best electronic services for you.This commitment, combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers PCB requirements – from front end engineering through to in time deliveries.
