Place of Origin: | China |
---|---|
Brand Name: | Cesgate |
Certification: | UL, IATF16949, ISO9001, ISO14001 |
Model Number: | NA |
Minimum Order Quantity: | 1PCS( NO MOQ) |
Price: | $1.00 |
Packaging Details: | PCB: Vacuum Packing / PCBA: ESD + vacuum Packing |
Delivery Time: | 3-7 working days |
Payment Terms: | T/T, L/C |
Supply Ability: | 13kk soldering spot/day |
X-Ray Inspection: | 2D X-Ray, 3D X-Ray | BGA Rework: | Yes |
---|---|---|---|
Material: | FR4, FR4 High TG, Rogers, Etc. | Certificate: | UL, RoHS, ISO9001, ISO14001 |
Warranty: | 1 Year | Layer: | 2-68 Layers |
SMT Line: | 4 | Size: | Standard |
Technical Parameter | Description |
---|---|
SMT Line | 4 |
Blind/Buried Vias | Yes |
BGA Rework | Yes |
Warranty | 1 Year |
Layer | 2-68 Layers |
X-Ray inspection | 2D X-Ray, 3D X-Ray |
Min. package | 03015/01005/0201 |
Impedance Control | Yes |
Size | Standard |
Certificate | UL, RoHS, ISO9001, ISO14001 |
intro
SMT and DIP are both ways of integrating parts on the PCB board, the main difference is that SMT does not require drilling on the PCB, and in DIP requires inserting the PIN pin of the part into the already drilled hole.
SMT(Surface Mounted Technology)
Surface mount technology, the main use of the mounting machine is to mount some micro parts to the PCB board, its production process is: PCB board positioning, printing solder paste, mounting machine, back welding furnace and finished inspection. With the development of science and technology, SMT can also be mounted on some large-size parts, such as some large-size mechanism parts can be mounted on the host board.
SMT integration is sensitive to positioning and part size, and solder paste quality and printing quality also play a key role.
DIP
DIP is the "plug-in", that is, to insert parts on the PCB, due to the large size of the parts and not suitable for mounting or the manufacturer's production process can not use SMT technology to integrate parts in the form of plug-ins. At present, there are two realization methods of artificial plug-in and robot plug-in in the industry, and the main production process is: adhesive (to prevent tin plating to where it should not be), plug-in, inspection, over-wave welding, brush plate (to remove the stain left in the furnace process) and made inspection
Our Main PCBA customization service focuses on Motherboard PCBA, Main Printed Circuit Assembly, and Main Printed Circuit Assembly.
The Main PCBA will be packaged in an ESD bag and put in a cardboard box with foam padding. The box will be sealed with a tamper-evident tape before shipment.
The PCBA will be shipped via a third-party courier such as FedEx or UPS. All shipments will be tracked to ensure safe delivery.
