Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL, IATF16949, ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk soldering spot/day
Product Name: Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR Feature: Multilayer/ PCBA
Board Thickness: 0.2mm-6.5mm HDI Type: 1+n+1、2+n+2、3+n+3
High-end Equipment: FUJI NXT3/XPF Laminator Shape: Retangular/Round/Slots/Cutouts/Complex/Irregular
Test: AOI/ X-Ray/Flying-Probe/Function Test Other Service: Components Purchase /Assembly/Custom Packaging
High Light:

Flex Grid Multilayer PCB Assembly Service

,

PCL-370HR PCB Assembly Service

Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR



At CESGATE, we have a production plant of more than 1,900 m² equipped with 9 PCB assembly lines, with SPI and AOI optical inspection machines, which allow us to guarantee product quality and meet production challenges with a high level of integration. As a result, we are able to offer turnkey products and pcb assembly with a quality in line with the most demanding markets.


We have a separate test area to check each and every component we manufacture, to ensure that the highest quality standards are met. Electrical safety, compatibility, performance, ageing tests or stress tests are some of the tests that all our equipment must pass satisfactorily.


We produce prototypes, pre-series, series production or mass production in line.


We produce from the electronics to the final product including the enclosure, wiring, packaging or the final product packaging. We accompany you throughout the entire process with all our resources.

Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR 0Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR 1





CESGATE PCB Assembly Welding Quality Control:


Features of PCBA

PCBA is the abbreviation of Printed Circuit Board +PCB Assembly, which means that PCBA is loaded by SMT from the PCB empty board, and then goes through the whole process of DIP plug-in. Note: Both SMT and DIP are ways of integrating parts on a PCB. The main difference is that SMT does not require drilling holes in the PCB. In DIP, the PIN pins of the part need to be inserted into the already drilled holes. SMT (Surface Mounted Technology) surface mount technology mainly uses a placement machine to mount some tiny parts on a PCB. The production process is: PCB board positioning, solder paste printing, placement machine installation, reflow oven and finished product inspection. DIP means "plug-in", that is, inserting parts on the PCB board. This is to integrate parts in the form of plug-ins when some parts are larger in size and not suitable for placement technology. The main production processes are: glue, plug-in, inspection, wave soldering, printing, finished product inspection.



Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm





Company Profile



In business since 2010, CESGATE mainly provides pcb fabrication and design service for customers from all over the world. We have ISO and UL certificate,and honored as HI-TECH enterprise by Chengdu goverment.
As a professional PCB factory , we can provide prototype and low-to-mid volume PCB fabrication and design services for our customers. We are in Chengdu, China, which is the largest center of technology and electronics manufacturing in the world. Cooperating with our engineering team, quality team, these allow us to offer our customers low-cost, One-stop PCB assembly Services.

Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR 2Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR 3Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR 4Fuji PCB Assembly Service Flex Grid Multilayer BOM 1206 PCL-370HR 5



FAQ

Q: What are the main products of your PCB/PCBA services?
CESGATE: Automotive, Military, Aerospace, Industry Control, Medical care, IOT, Smart Home, Robot, Auto parts, Camera, UAV.
Q: What is your minimum order quantity (MOQ)?
CESGATE: Our MOQ is 1 PCS, we are able to handle Small as well as large volume production with flexibility.
Q: Are you factory?
CESGATE: Our factory is located in Building 6, Fuyuan industrial park, Qiaotang road, Fuyong street , Shenzhen city, China.
Q: How about the shipping cost?
CESGATE: The Shipping cost depends on the destination, the weight and volume of the goods as well as the quotation of DHL/FEDEX/ freight forwarder at that time. You can inform us of the transportation way you need before placing an order.
