ISO9001 SMD Automated Quick Turn PCB Assembly Wave Soldering

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk soldering spot/day
Product Name: SMD Automation Manufacturing Quick Turn 2022 Main PCBA Customized Logo Feature: SMD/PCBA
High-end Equipment: FUJI NXT3/XPF Laminator Material: FR4/M4/M6/Rogers/TU872/IT968
Lead Time: 3-7 Working Days Test: AOI/SPI/XRAY/First Article Inspection
Warranty: 3 Months Profiling Punching: Routing/V-CUT/Beveling
High Light:

SMD automated pcb assembly

,

automated pcb assembly wave soldering

,

quick turn pcb assembly wave soldering

SMD Automation Manufacturing Quick Turn 2022 Main PCBA Customized Logo





Our Strengths



GESGATE is experienced in engineering, eliminate problems and traps before production. In the PCB industry for more than ten years, we build a standardized and rigorous process and system has been established to effectively reduce quality problems. We have professional PCB manufacturing, main PCBA and component procurement team, providing one-stop service, saving time and effort. We can provide services such as fast delivery, minimum mount. We have expedited 8-hour delivery, with a 48-hour delivery rate of over 95% and 03015, 01005, 0201, 0402 in minimum mount. Actually we are experienced in engineering, eliminate problems and traps before production. Professional PCB manufacturing, main PCBA and component procurement team, providing one-stop service, saving time and effort.





Our Production Lines



Our company currently has 7 wave soldering production lines and 10 post-DIP soldering lines. We can make special fixtures according to customer requirements and product conditions to ensure product reliability and effectively improve plug-in efficiency.

Our DIP post-welding personnel have rich experience, and have formulated detailed standardized operation guidelines and SOP operation instructions to meet the high-quality requirements of high-end customers.





Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm





Company Profile



Producing a qualified product is crucial to CESGATE and to you. To ensure main PCBA are compliant we use a number of inspection and Quality assurance procedures. Including Automatic Optical Inspection equipment and CAD software as well as continuous improvements. We are accredited to ISO9001:2015 as well as being a preferred supplier to many of our customers. With access to global suppliers, and distribution networks we can source parts for your assemblies as needed. Using our own in-house Stock and MRP system which links to our production data we are able to manage Inventory levels, lead times and buffer stocks to meet your deadlines.



ISO9001 SMD Automated Quick Turn PCB Assembly Wave Soldering 0ISO9001 SMD Automated Quick Turn PCB Assembly Wave Soldering 1ISO9001 SMD Automated Quick Turn PCB Assembly Wave Soldering 2ISO9001 SMD Automated Quick Turn PCB Assembly Wave Soldering 3

FAQ



Q: Popular field?
CESGATE: Semiconductor, Smart Home, Medical Products, Smart Wearable, Industrial Control, IOT etc.
Q: Can you give us a preferential discount?
CESGATE: Of course, we will offer a preferential discount for your large orders and confirm the order quickly.
Q: Why choose us?
CESGATE: Professional and experienced R&D team. Advanced production equipment, scientific and reasonable process flow.
Reliable and strict quality control system. We test all our products before shipment to make sure everything is in perfect condition.
Q: How long does it take for PCB quote?
CESGATE: Normally 12 hours to 48 hours as soon as receive internal engineer evaluate confirmation.
