OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: N/A
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 1-30 working days
Payment Terms: T/T, L/C
Supply Ability: 30,000pcs/month
Product Name: Electronic Service OEM Rigid Flexible RF PCB Board Microwave Electronic Board Base Material: FR-4, TACONIC, Aluminum, CEM-3, Metal/ceramic/aluminum Base
Solder Mask: Green, White Black Green Blue Red, Green Or Other Color As You Want, Green/blue, Green Black Bule White Testing Service: 100% Electrical Test, Fly-probe, Function Testing, 100% E-testing, Flying Probe Testing
Min. Line Spacing: 0.003", 4mil, 3 Mil (0.075 Mm), 0.1mm4mil), 0.1mm Test: Customer's Test Method, Flying Probe Test, E-test/Fixture Test/Functional Test
Surface Finishing: HASL, HASL Lead Free, OSP, Immersion Gold, Green Oil Min. Hole Size: 0.20mm, 8 Mil/6 Mil, 4mil, 3.0*4, 1
High Light:

OEM Rigid microwave pcb board

,

flexible circuit pcb Immersion Gold

,

microwave pcb board Immersion Gold

Electronic Service OEM Rigid Flexible RF PCB Board Microwave Electronic Board





Metal Core PCB Manufacturing Customized PCB Rigid Printed Circuit Boards



CESGATE has rich experience in the production of difficult RF PCB board, and has taken over many customers who failed to make RF PCB board in other factories, and handed over perfect products.Our company currently has 7 wave soldering production lines and 10 post-DIP soldering lines. We can make special fixtures according to customer requirements and product conditions to ensure product reliability and effectively improve plug-in efficiency.We always provide high quality, technically advanced products within the customer’s timescales so that we can provide the best electronic services for you.For each process, CESGATE has formulated perfect operation instructions, and customized targeted inspection standards according to products in different industries, so as to improve the pass-through rate of products from each link.



Briefly Introduce Our Strength







Industrial application



High-power industrial applications of RF PCBs are common. These electronic components control the mechanisms used in factories and manufacturing facilities and must withstand the harsh conditions commonly found in industrial installations. This can include anything including harsh chemicals, vibrating machinery and rough handling.
In such a rapidly challenging environment, industry standards are equally stringent. Currently, thick copper PCBs (much thicker than standard ounce PCBs) are often seen in other applications. This PCB is helpful for high current industrial applications and battery chargers.
1. Industrial Equipment: Many drills and presses used in manufacturing operate using PCB-controlled electronics.
2. Measuring Equipment: Equipment used to measure and control pressure, temperature and other variables in industrial manufacturing processes.
3. Power equipment: DC-AC power inverter, solar cogeneration equipment and other power control equipment.



PCB Capacities and Technical Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm




Advanced PCB Manufacturing and PCB Assembly Equipment



CESGATE has imported the advanced machinery from US,Japan,German and Israel to improve our production and technical ability.We have set a great example the PCB field of flying probe testing,buried and blind via and special controlled impedance.We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.



OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 0OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 1OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 2OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 3OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 4OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 5OEM Rigid Flexible Circuit Microwave Pcb Board Immersion Gold 6
