2-68 Layers High TG Main PCBA Medical PCB Assembly 600mm*1200mm

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk soldering spot/day
Product Name: High TG Medical Equipment HASL ENIG Assembly Main PCBA Soldering Services SMT Production Line: 14
High-end Equipment: FUJI NXT3/XPF Laminator Material: FR4/M4/M6/Rogers/TU872/IT968
Lead Time: 3-7 Working Days Test: AOI/SPI/XRAY/First Article Inspection
Warranty: 3 Months MOQ: No MOQ
High Light:

68 Layers medical pcb assembly 600mm*1200mm

,

68 Layers High TG Main PCBA 600mm*1200mm

,

68 Layers medical pcb assembly 600mm*1200mm

High TG Medical Equipment HASL ENIG Assembly Main PCBA Soldering Services





CESGATE's Advantages


1. Born from technology, we understand R&D needs.
2. Break through the barriers from design to production.
3. Quality traceable.
4. Fast and on time delivery.



SMT assembly quality control



①Adhesive cardboard: Test whether the SMT placement position is correct, greatly reduce the SMT trial production time and the waste of components, and effectively ensure the quality of SMT
②Intelligent first-piece detector: detects wrong materials, missing parts, polarity, orientation, silk screen, etc., mainly used in the detection of first-piece; compared with manual detection, the accuracy is higher and the speed is increased by 50%+
③SPI-Automatic 3D Solder Paste Thickness Gauge: Detects various solder paste printing quality problems such as missing printing, less tin, more tin, continuous tin, offset, poor shape, board surface pollution, etc.
④AOI: Detect various problems after placement: short circuit, material leakage, polarity, displacement, wrong parts
⑤Xray: Open circuit and short circuit detection of BGA, QFN and other devices.



Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm





Company Introduction



Through data management, CESGATE has greatly improved production efficiency in a system-driven mode, and achieved completion within 24 hours from order placement to delivery, helping users shorten the research and development cycle. As a promoter and practitioner of Industry 4.0, CESGATE will accelerate its own digital and intelligent iteration, and actively create a "new lighthouse" for intelligent manufacturing in the electronics industry.



From smartphones to kitchen appliances, electronics play an important role in our daily work. At the heart of every electronic product is the Printed Circuit Board (PCB). It is the foundation of most electronics today. These components have a large number of configurations that allow them to provide various functions. With the expansion and development of electronic products in various industries, Main PCBAs  applications are also constantly developing. Today, the use of Main PCBA covers almost every industry and is constantly evolving into new industries and applications. Main PCBAs are the main functional center of most electronic products in the modern world. Circuit boards connect components to each other through a series of related circuits.

2-68 Layers High TG Main PCBA Medical PCB Assembly 600mm*1200mm 02-68 Layers High TG Main PCBA Medical PCB Assembly 600mm*1200mm 12-68 Layers High TG Main PCBA Medical PCB Assembly 600mm*1200mm 22-68 Layers High TG Main PCBA Medical PCB Assembly 600mm*1200mm 3

FAQ



Q: MOQ?
CESGATE: There is no MOQ in POE. We are able to flexibly handle small and large batches.
Q: Do you have any other services?
CESGATE: We mainly focus on the procurement services of PCB + assembly + components. In addition, we can also provide programming, testing, cable, housing assembly services.
Q: What is your inspection policy? How do you control the quality?
CESGATE: In order to ensure the quality of PCB products, flying probe inspection is usually used; electrical fixtures, automatic optical inspection (AOI), BGA parts x-ray inspection, first article inspection ( FAI) etc.
Q: What service do you have?
CESGATE: We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other value-added service.
