| Product Name: | Automotive Aerospace PCB Assembly Service Electronics Manufacturing EMS | Feature: | Aerospace |
|---|---|---|---|
| Min Package: | 01005 | Profiling Punching: | Routing/V-CUT/Beveling |
| High-end Equipment: | FUJI NXT3/XPF Laminator | Minimum Finished Aperture: | 0. 10mm |
| Test: | AOI/ X-Ray/Flying-Probe/Function Test | Other Service: | Components Purchase /Assembly/Custom Packaging |
| High Light: | Aerospace PCB Assembly Service,EMS PCB Assembly Service,Automotive Multilayer Pcb Assembly |
||
Automotive Aerospace PCB Assembly Service Electronics Manufacturing EMS
PCBA is the abbreviation of Printed Circuit Board Assembly in English, that is to say, the empty PCB board passes through the SMT upper part, or the whole process of DIP plug-in, referred to as PCBA.
Both SMT and DIP are ways of integrating parts on the PCB. The main difference is that SMT does not need to drill holes on the PCB. In DIP, the PIN pins of the parts need to be inserted into the drilled holes.
SMT (Surface Mounted Technology):
Surface mount technology mainly uses the mounter to mount some tiny parts on the PCB. The production process is: PCB board positioning, solder paste printing, mounter placement, reflow oven and finished inspection. With the development of technology, SMT can also mount some large-size parts, for example, some larger-sized mechanical parts can be mounted on the motherboard.
SMT integration is very sensitive to positioning and the size of parts. In addition, the quality of solder paste and printing quality also play a key role.
DIP:
DIP is "plug-in", which is to insert parts on the PCB board. Due to the large size of the parts and it is not suitable for placement or the manufacturer's production process cannot use SMT technology, the parts are integrated in the form of plug-ins. At present, there are two implementation methods of manual plug-in and robot plug-in in the industry. The main production process is: sticking back glue (to prevent tin from being plated where it should not be), plug-in, inspection, wave soldering, and brushing (remove the Stains left in the process) and finished inspection.
Technical Requirement for PCB Assembly
Professional Surface-mounting and Through-hole soldering technology
High Standard SMT&Solder Assembly Line
ICT(In Circuit Test),FCT(Functional Circuit Test) technology
PCB Assembly With CE, FCC, Rohs Approval
Nitrogen gas reflow soldering technology for SMT
High density interconnected board placement technology capacity
Various sizes like 1206, 0805, 0603 components SMT technology
Specification
|
Items |
Capabilities |
|
|
1 |
Layers |
2-68L |
|
2 |
Maximum machining size |
600mm*1200mm |
|
3 |
Board thickness |
0.2mm-6.5mm |
|
4 |
Copper thickness |
0.5oz-28oz |
|
5 |
Min trace/space |
2.0mil/2.0mil |
|
6 |
Minimum finished aperture |
0. 10mm |
|
7 |
Maximum thickness to diameter ratio |
15:1 |
|
8 |
Via treatment |
Via, blind&buried via, via in pad, Copper in via … |
|
9 |
Surface finish/treatment |
HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating |
|
10 |
Base Material |
FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350, |
|
11 |
Solder mask color |
Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black |
|
12 |
Testing Service |
AOI, X-Ray, Flying-Probe, Function Test, First Article Tester |
|
13 |
Profiling Punching |
Routing,V-CUT,Beveling |
|
14 |
Bow&twist |
≤0.5% |
|
15 |
HDI type |
1+n+1,2+n+2,3+n+3 |
|
16 |
Min mechanical aperture |
0.1mm |
|
17 |
Min laser aperture |
0.075mm |
Company Profile
CESGATE with customers to provide them with the highest-quality PCB and PCB assembly electronic manufacturing services to achieve their goals. Our flexibility is in meeting customer requirements and our superior customer service. We help companies introduce their new products to market in the fastest time possible by providing high quality, quick-turn assembly.We provide one-stop electronic manufacturing service to help you qualify your designs and provide quality samples to your customers.
