Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk solding spot/day
Product Name: Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling Feature: Pcb Material Fr4
High-end Equipment: FUJI NXT3/XPF Laminator Material: FR4/M4/M6/Rogers/TU872/IT968
Test: AOI/SPI/XRAY/First Article Inspection QTY: Support Prototype And Batch Production
Name: PCB Board Production, Water Heater PCBA, Shenzhen Manufacturer One-stop Turnkey OEM Electronic Pcb Pcba Design, Electronic PCB PCBA Production Turnkey Circuit Board Assembly Application: Consumer Electronics, Electronic Sensor, Solar Panels Pcb, Rigid Fpc, Electronic Products
High Light:

Mechanical Keyboard Fr4 Pcb Electronic Board

,

Hot Air Solder Leveling Pcb Board

Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling





CESGATE conducts internal quality control in strict accordance with ISO requirements. The company is equipped with nearly 20 professional quality management and inspection personnel, more than 10% of the total number of people. The company is equipped with more than 40 sets of advanced testing equipment such as AOI optical detector, electrostatic tester, transistor grapher, etc., which can effectively control the production process. Quality risks in all aspects.



CESGATE's advantages of turnkey PCB assembly



1. As a one-stop service shop, thoughtful Turnkey PCB Assembly will start from your inquiry to after-sales.
2. Free design stack-up service, modify until you are satisfied.
3. Each process is monitored by specialized quality inspection personnel to detect problems in time and solve them as soon as possible.
4. Expedited service is supported.

5. Turnkey PCB Assembly





Specification



Article Description Capability
Material Laminate materials FR4, High TG FR4, High Frequency, Alum, FPC...
Board Cutting Number of layers 1-48
Min.thickness for inner layers
(Cu thickness are excluded)
0.003”(0.07mm)
Board Thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist no more than 7/1000
Copper Weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)
Solder Mask Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
Max Size of Finish Board 700*460mm
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline Square,circle,irregular(with jigs)
Package QFN,BGA,SSOP,PLCC,LGA









Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling 0Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling 1Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling 2Pcb Material Fr4 Mechanical Keyboard Pcb Electronic Board Hot Air Solder Leveling 3



Q.Shipping cost?
CESGATE: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
Q: What certificates do you have?
CESGATE: We have ISO 9001, ISO14001 and UL certificates.
Q: Which express companies do you cooperate with?
CESGATE: We cooperate with express companies, including DHL, FedEX, UPS, TNT and EMS. And we also have our own freight forwarders, with lower shipping fees.
Q: What modes of transport are there?
CESGATE: Usually includes express, air shipment, rail shipment and sea shipment.
Q: Popular field?
CESGATE: Semiconductor, Smart Home, Medical Products, Smart Wearable, Industrial Control, IOT etc.
