Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL, IATF16949, ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk soldering spot/day
Product Name: Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing Feature: Quick Turn PCB
Min Package: 03015 Board Thickness: 0.2mm-6.5mm
High-end Equipment: FUJI NXT3/XPF Laminator Shape: Retangular/Round/Slots/Cutouts/Complex/Irregular
Test: AOI/ X-Ray/Flying-Probe/Function Test Surface Treatment: OSP ,Immersion Gold, Immersion Tin ,Immersion Ag
High Light:

Astra Mt77 PCB Assembly Service

,

Emu8086 Central Processing PCB Assembly Service

Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing





Technical Requirement for PCB Assembly service

1) Professional Surface-mounting and Through-hole soldering Technology

2) Various sizes like 1206, 0805, 0603 components SMT technology

3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

4) PCB assembly service With CE, FCC, Rohs Approval

5) Nitrogen gas reflow soldering technology for SMT.

6) High Standard SMT&Solder Assembly Line

7) High density interconnected board placement technology capacity.



.Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing 0



Often encountered materials in PCB assembly service





What is PCB Components Sourcing?


PCB Component sourcing refers to the purchasing the PCB components to be assembled onto the printed circuit board.Component sourcing can be done in many ways.You can have the suppliers purchase components from authorized and reliable distributors of their choice and deliver to you by order.You can also recommend a distributor where the supplier can source the components from and deliver to you.Still, you can opt to source for some components and let another supplier source the rest.Component sourcing can either be done locally or from abroad. International component sourcing usually takes around 5-10 working days depending on the duration of customs clearance.Local sourcing, on the other hand, takes a shorter time. It is therefore preferred, especially if all the required components are available because it helps save on time and production cost.







Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm



Advantages of CESGATE



1. 1600 square meters central warehouse
2. Full range of Yageo, Murata, Avx, Kemet RC
3. Temperature and humidity control, first in first out mechanism

4. Solve the problem of R&D samples
5. Professional supply chain team support
6. R&D procurement can also enjoy VIP PCB Assembly service



Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing 1Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing 2Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing 3Prototype PCB Assembly Service Multilayer Quick Turn Circuit Board Manufacturing 4






FAQ



Q: DO YOU TEST ALL YOUR GOODS BEFORE DELIVERY?
CESGATE:

1. Our products are all original, and we will test the goods before shipment by professional machines like KEYSIGHT E4991A and KEYSIGHT E4980.
2. If The buyer need Test Report, we can send the product to anthoritative institution such as White horse Laboratories(SZ) Limited,Global Electronics Testing,etc.

Q: What are the types of solder mask?
CESGATE: There are traditional epoxy resin IR baking type, UV curing type, Liquid Photo Imageable Solder Mask and Dry film solder mask. Currently, the liquid solder mask is the main type.

Q: How can we guarantee quality?
CESGATE: Always a pre-production sample before mass production;
Always final Inspection and test report before shipment;
Q: What is the difference between the HDI board and the general circuit board?
CESGATE: Most of HDI use laser to form holes, while general circuit boards only use mechanical drilling, and HDI boards are manufactured by the build-up method (Build Up), so more layers will be added, while general circuit boards are only added once.
