Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL, IATF16949, ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk soldering spot/day
Product Name: Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype Feature: PCBA/Prototype
Min Package: 03015 High-end Equipment: FUJI NXT3/XPF Laminator
Test: AOI/ X-Ray/Flying-Probe/Function Test Other Service: Components Purchase /Assembly/Custom Packaging
Copper Thickness: 1oz, 1/2OZ 1OZ 2OZ 3OZ, 0.25 Oz -12 Oz, 0.5OZ-6OZ, 0.25OZ~12OZ Min Spacing: 3 Mil
High Light:

SMT SMD Prototype PCB Assembly Service

,

1oz PCB Assembly Service

,

Fast Multilayer PCBA Assembly Service

Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype





PCB Assembly Service substrate


The base material is generally classified according to the insulation, material composition or flame resistance of the substrate. The common raw materials are bakelite, glass fiber, and various plastic boards. Manufacturers of PCB substrates generally use an insulating prepreg composed of glass fiber non-woven fabrics and epoxy resin resins, and then press them with copper foil to form a copper foil substrate for use.

The following are the more common types of PCB substrates:

FR-4: Glass fiber + epoxy resin. It is the most commonly used PCB material, but the Tg is only about 130. If the subsequent processing environment of the product or the operating environment temperature is high, High Tg FR-4 is recommended.
High Tg FR-4: Glass fiber + epoxy resin, the use is second only to FR-4. Tg above 150°C is High Tg.
CEM-1: The center is tissue paper, and the surface is covered with glass cloth + epoxy resin.
CEM-3: The center is glass non-woven cloth, and the surface is covered with glass cloth + epoxy resin.
Ceramic substrate (Ceramic PCB): ceramic powder + glass fiber.
Teflon PCB (Teflon PCB): Teflon + glass fiber.





Who are we?



Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm





Company Profile



CESGATE is the professional PCB and PCBA Manufacturer, can provide one-stop service from PCB/PCBA Design, PCB/PCBA Clone, PCB manufacturing, Components sourcing, PCB Assembly Service, and fully product assembly and test. We have got certification of ISO 9001, ISO 13485 and UL. Our capacity including: 1-32 layers FR4 PCB board manufacturing, 1-12 layers Flexible PCB manufacturing, Aluminum PCB and Ceramic PCB manufacturing, can finish about 324000pcs PCBA per months.

Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype 0Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype 1Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype 2Fast Multilayer PCBA Customized PCB Assembly Service SMT SMD Prototype 3






FAQ



Q: What service do you have?
CESGATE: We provide one-stop solutions including PCB manufacturing, SMT, component sourcing, final assembly, testing and other services.
Q: What is needed for PCB & PCBA quotation?
CESGATE: For PCB: Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness) and quantity you need.
For PCBA: Files mentioned above, BOM, pick and place file.
Q: Are my files safe?
CESGATE: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.
If requested by the client, we will sign an NDA subject to local laws on the client's side and promise to keep client data highly confidential.
Q: What are the main products of your PCB/PCBA services?
CESGATE: Automotive, Military, Aerospace, Industry Control, Medical care, IOT, Smart Home, Robot, Auto parts, Camera, UAV.
