Combination Through Hole SMT Prototype Board Assembly Fast Turn

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: NA
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 3-7 working days
Payment Terms: T/T, L/C
Supply Ability: 13kk solding spot/day
Product Name: Combination Through Hole Volume Production Turnkey PCB Assembly SMT Fast Turn Feature: Combination Through Hole
SMT Production Line: 14 High-end Equipment: FUJI NXT3/XPF Laminator
Material: FR4/M4/M6/Rogers/TU872/IT968 Max Size Of Finish Board: 700*460mm
Test: AOI/SPI/XRAY/First Article Inspection Inspection Standard: IPC Class II/ IPC Class III
High Light:

SMT through hole prototype board

,

through hole prototype board Fast Turn

,

SMT prototype assembly Fast Turn

Combination Through Hole Volume Production Turnkey PCB Assembly SMT Fast Turn





CESGATE's Advantages


1. Material arrives, arrange assembly immediately
2. On the SMD welding production line,
3. Accelerate the product development process





CESGATE Turnkey PCB Assembly Welding Quality Control


1. The SMT line is equipped with high-end equipments, high-precision and high-yield processing
2. Quality inspection and control are carried out in each processing link to prevent defective products from flowing into the next link.
3. Equipped with a number of quality personnel throughout the sampling inspection.





Technical Requirement for Turnkey PCB Assembly



1) Professional Surface-mounting and Through-hole soldering Technology

2) Various sizes like 1206, 0805, 0603 components SMT technology

3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

4) Turnkey PCB Assembly With CE, FCC, Rohs Approval

5) Nitrogen gas reflow soldering technology for SMT.

6) High Standard SMT&Solder Assembly Line

7) High density interconnected board placement technology capacity.





Company Introduction



Chengdu Cesgate Technology Co., Ltd. is located in Chengdu High-tech Zone, Sichuan, China, with a standardized modern industrial plant of about 4,000 square meters. The company is a leading electronic manufacturing service provider in Chengdu. The factory has passed the ISO9001 quality management system certification and ISO14001 environmental protection system certification issued by SGS. Since its establishment, the company has adhered to the business philosophy of "professional quality, continuous innovation, and high-quality service".



Specification



Article Description Capability
Material Laminate materials FR4, High TG FR4, High Frequency, Alum, FPC...
Board Cutting Number of layers 1-48
Min.thickness for inner layers
(Cu thickness are excluded)
0.003”(0.07mm)
Board Thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist no more than 7/1000
Copper Weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)
Solder Mask Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
Max Size of Finish Board 700*460mm
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline Square,circle,irregular(with jigs)
Package QFN,BGA,SSOP,PLCC,LGA









Combination Through Hole SMT Prototype Board Assembly Fast Turn 0Combination Through Hole SMT Prototype Board Assembly Fast Turn 1Combination Through Hole SMT Prototype Board Assembly Fast Turn 2Combination Through Hole SMT Prototype Board Assembly Fast Turn 3





FAQ





Q: Which express companies do you cooperate with?
CESGATE: We cooperate with express companies, including DHL, FedEX, UPS, TNT and EMS. And we also have our own freight forwarders, with lower shipping fees.
Q: What modes of transport are there?
CESGATE: Usually includes express, air shipment, rail shipment and sea shipment.
Q: Popular field?
CESGATE: Semiconductor, Smart Home, Medical Products, Smart Wearable, Industrial Control, IOT etc.
Q: Can you give us a preferential discount?
CESGATE: Of course, we will offer a preferential discount for your large orders and confirm the order quickly.
Q: Why choose us?
CESGATE: Professional and experienced R&D team. Advanced production equipment, scientific and reasonable process flow.
Reliable and strict quality control system. We test all our products before shipment to make sure everything is in perfect condition.
Q: How long does it take for PCB quote?
CESGATE: Normally 12 hours to 48 hours as soon as receive internal engineer evaluate confirmation.
