ECS Motherboard TX RX Circuit 2 Sided PCB DetDection Range 80-280CM

Basic Information
Place of Origin: China
Brand Name: CESGATE
Certification: UL、IATF16949、ISO9001
Model Number: N/A
Minimum Order Quantity: 1PCS( NO MOQ)
Price: Negotiable (Depends on your GERBER and BOM)
Packaging Details: PCB: Vacuum Packing / PCBA: ESD Packing
Delivery Time: 1-30 working days
Payment Terms: T/T, L/C
Supply Ability: 30,000pcs/month
Product Name: High Quality TX RX Circuit RF PCB Board Dual Mainboard EAS Mother Board Board Thickness: 1.6mm, 0.2-6.0mm, 0.4~3mm, 0.4mm-3.2mm, /
Working Mode:: TX+RX Board Size:: 78x102mm
Logo Option:: Silk Print, Laser, Stamped,etching Material:: Copper-nickel-zinc / Tinplate/ Stainless Steel
DetDection Range: 80~280CM (also Depend On Tag) Function: High Sensitivity,less False.Stable Performance
High Light:

ECS Motherboard 280CM

,

TX RX Circuit 2 sided pcb

,

2 sided pcb 280CM

High Quality TX RX Circuit RF PCB Board Dual Mainboard EAS Mother Board





Metal Core PCB Manufacturing Customized PCB Rigid Printed Circuit Boards



CESGATE is an Internet + Industry 4.0 intelligent manufacturing enterprise, dedicated to helping global companies solve the problems of precision, difficulty, special, slow delivery of small and medium orders and difficult procurement. CESGATE relies on new technologies such as big data, cloud computing, and the Internet of Things, combined with the self-developed intelligent quotation, inspection, assembly, and production scheduling system, to achieve "smart factory, flexible manufacturing".



What CESGATE provide





Medical equipment



As the development of electronics becomes more efficient and dense, the medical applications of these electronic devices continue to grow, leading to endless new possibilities.At the heart of these medical devices is the PCB. RF PCB board in the medical industry are highly specialized to accommodate the unique constraints of medical devices. In many medical applications, small packages are required to meet the size requirements for implants or emergency room monitors. Therefore, medical PCBs tend to be specialty high-density interconnect PCBs, also known as HDI PCBs. Medical  RF PCB board can also be made with flexible substrates that allow the PCB to bend during use, which is essential for both internal and external medical devices.Medical RF PCB board  are held to a higher standard than most other PCB types due to the health concerns associated with them. In addition to complying with strict medical regulations, repeatability and reliability are two essential qualities that medical PCB suppliers must achieve.Medical PCB applications are growing as fast as the medical device industry itself. Some of the most common medical  RF PCB board applications include:

1. Monitors: Personal and healthcare monitors, including blood glucose monitors, heart rate and blood pressure monitors, and more.
2. Scientific Instruments: Medical research uses a large number of scientific instruments to study diseases and test the results of patients. These include electron microscopes, photometers, and generator and compressor control systems, among others.
3. Monitors: Personal and healthcare monitors, including blood glucose monitors, heart rate and blood pressure monitors, and more.





PCB Capacities and Technical Specification



NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm




Advanced PCB Manufacturing and PCB Assembly Equipment



CESGATE has imported the advanced machinery from US,Japan,German and Israel to improve our production and technical ability.We have set a great example the PCB field of flying probe testing,buried and blind via and special controlled impedance.We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.
